Thomas & Betts 54460 Method Lug

Manufacturer: ABB Thomas & Betts | Catalog # 54460 | Codale Part # 3289016
$1,553.99/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
47 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet Product Catalog Page
Copper One-Hole High Voltage Lug, Long Barrel, Blind End, Max 15kV, Wire Size 2/0 AWG, 1/2 Inch Bolt Size, Tin Plated, Die Code 45R, Black Rounding

Technical Information

Barrel Length
Long
Barrel Shape
Standard
Barrel Type
Long, Straight
Cable Size
2/0 AWG
Conductor Size
2/0 AWG
Insulated?
No
Material
Copper
Number of Holes
1 Hole
Number of Studs
1
Standard
UL E9809
Temperature Rating
105 degrees C
Tongue Angle
Straight
Tongue Width
Standard
Type
High Voltage
Voltage
15 kV
Wire Size
00 AWG

Manufacturer Information

Brand
ABB
Sub Brand
Color-Keyed®

General Product Info

12-Digit UPC
786210544601
Color
Black
Finish
Tin Plated
Product UPC
78621054460
Shape
Round
Weight
0.0900 lb
Features
  • High conductivity wrought copper, tin plated. Cable Area Clearly Identified on Lug.
  • Recommended for up to 15KV applications, installed with standard T&B tools with special rounding dies.
  • The rounding die overlapped compressions provide a smooth round surface. This combined with the tapered barrel ends, addresses the controlling of potentially damaging electrical stresses of high voltages.
Notes
  • Cat No. TBM15500 Die Adaptor required for TBM15I tool.
  • Cable Size: Concentric and compact strandings.
