Burndy GB4C Mechanical Grounding Connector, Cable to 1/4" Thick Bar, 8 AWG (Sol)- 4 AWG (Str), 3/8" Stud1-1/4" Width

Manufacturer: Hubbell-Burndy | Catalog # GB4C | Codale Part # 3297115
$41.81/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Buy American Compliant Buy American Compliant Primary Spec Sheet
Mechanical Grounding Connector, Cable to 1/4" Thick Bar, 8 AWG (Sol)- 4 AWG (Str), 3/8" Stud

Technical Information

Applications
For Joining Cable to 1/4 in Thick Bar, for Direct Burial in Concrete or Ground
Barrel Type
Straight
Bolt Size
3/8 IN
Cable Size
4/0 AWG Solid And Stranded
Conductor Size
8-4 AWG
Conductor Type
Copper
Direct Burial?
Yes
Material
Copper
Mounting Type
3/8 in Hole
Number of Holes
2
Plated?
No
Plating Type
Unplated
Standard
3R,C22.2 No. 0.4,C22.2 No. 18,C22.2 No. 94 Enclosures Types 1,UL 514C,UL467,UL50 Enclosures Types 1
Stud Size
3/8 in
Type
Mechanical

Manufacturer Information

Brand
Burndy
Sub Brand
MECHANICAL CONNECTOR

General Product Info

12-Digit UPC
781810231180
Color
Purple
Product UPC
78181023118
Weight
0.1540 lb

Dimensions

Height
1.49 Inch
Length
0.88 Inch
Overall Length
22 mm
Width
1.06 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
Mexico
CSA
No
Features
  • High copper alloy ground connector for joining a range of cable to 1/4\" thick bar
  • Type GB separates cable from bar
  • One-wrench installation
  • UL467 Listed
  • Suitable for Direct Burial in earth or concrete
