HWDK HBL7371 DUP RCPT,COMB 5-15RNON

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL7371 | Codale Part # 329768
$121.44/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Locking Devices, Twist-Lock®, Industrial, Combination Face Duplex Receptacle, 15A 125V/10A 250V,15A 125 V, 2-Pole 3-Wire Grounding, 5-15R and Non NEMA, Screw Terminal, Brown, 2) Feeds 1) Return

Technical Information

Amperage
15 Amp
Applications
Heavy Duty
Base Material
RTP
Conductor Size
14-10 AWG
Current
10 Amp
Dielectric Strength
Withstands 2,000V minimum
Face Material
RTP
Horsepower
0.5 hp
Material
Thermoplastic
NEMA
5-15R
Number of Phases
1 Phase
Number of Poles
2-2 Pole
Number of Wires
3,3
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
C22.2,CSA,No. 42 File 285,UL,UL498 File E2186
Tc Connection
Screw Terminal
Type
Combination Duplex Receptacles
Voltage
125/250 Volt
Wattage
1875 Watt
Wire Count
3
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Straight Blade

General Product Info

12-Digit UPC
783585237152
Color
Brown
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Product UPC
78358523715
Weight
0.25 lb

Dimensions

Height
0.88 Inch
Length
3.28 Inch
Width
1.5 in

Certifications and Compliance

Country of Origin
Puerto Rico
Features
  • Industrial
  • Combination Face Duplex Receptacle
  • 15A 125V/10A 250V
  • Standard
