Hubbell HBL7465-V 15A 125V Midget Twist-Lock VALISE Black Nylon Plug, Straight

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL7465V | Codale Part # 329777
$54.97/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Locking Devices, Midget Twist-Lock®, Valise®, Male Plug, 15A 125V, 2-Pole 2-Wire Non Grounding, NEMA ML-1P, Screw Terminal, Black.

Technical Information

Amperage
15 Amp
Applications
Industrial/Commercial
Conductor Size
14-12 AWG
Cord Type
Portable
Current
15 Amp
Grounding
No
Material
Composite
Mounting Type
Surface
NEMA
ML-1P
Number of Phases
1 Phase
Number of Poles
2 Pole
Number of Wires
2 Wire
Operating Temperature
-40 degrees C
Size
Midget Locking
Standard
Fed.Spec.W-C-596
Tc Connection
Pressure Screw Terminal
Type
Valise, Midget
Voltage
125 Volt
Wattage
1875 Watt
Wire Count
2
Wire Size
18-14 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock®, Valise®

General Product Info

12-Digit UPC
783585237282
Color
Black
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
Product UPC
78358523728
Weight
0.05 lb

Dimensions

Height
1.06 Inch
Length
1-1/4 Inch
Width
1.06 in

Certifications and Compliance

Country of Origin
China
Features
  • Fully insulated, abuse resistant nylon housing
  • Powerful, cord-gripping jaws
  • Totally insulated body adds extra measure of safety
  • Standard Product
