Hubbell HBL560R9W 60amp 4-Pole 5-Wire, 3phY 120/208V Pin & Sleeve Receptacle, IEC Watertight

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL560R9W | Codale Part # 330140
$939.34/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Heavy Duty Products, IEC Pin and Sleeve Devices, Industrial Grade, Female Receptacle, 60A 3-Phase Wye 120/208V AC, 4-Pole 5-Wire Grounding, Terminal Screws, Blue, Watertight

Technical Information

Amperage
60 Amp
Applications
High Ampacity Watertight Connections
Conductor Size
8-2 AWG
Current
60 Amp
Material
Thermoplastic
Mounting Type
Screw, Surface
Number of Phases
3 Phase
Number of Poles
4 Pole
Number of Wires
5 Wire Grounding
Operating Temperature
-40 degrees C
Size
Standard
Standard
Standard UL1682
Style
Receptacle
Tc Connection
Pressure Plate
Type
Single Flanged
Voltage
120/208 Volt
Wattage
12480 Watt
Wire Count
5
Wire Size
8-2 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Pin and Sleeve Devices

General Product Info

12-Digit UPC
783585405735
Color
Blue
Environmental Conditions
Watertight
Product Series
HBL Heavy Duty
Product UPC
78358540573
Weight
2.55 lb

Dimensions

Height
4.62 Inch
Length
6 Inch
Width
5.6 in

Certifications and Compliance

Certifications
CSA Certified,CSA Certified.,UL Listed,UL Listed
Country of Origin
USA
Features
  • Self-closing gasketed cover
  • Color coded housings for easy identification
  • Super tough insulated non-metallic housing
  • Watertight
