Hubbell H320B 20/16A 250V AC IEC Straight Blade Appliance Inlet

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # H320B | Codale Part # 3329505
$39.08/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Straight Blade Devices, IEC 320 Devices, Inlet, 16A 250V, International Rated, Pressure Screw Terminal, Black, Single Pack.

Technical Information

Amperage
16 Amp
Applications
Heavy Duty Industrial
Conductor Size
14-12 AWG
Current
16 Amp
Dielectric Strength
Withstands 2,000V minimum
Material
Composite
Mounting Type
Screw
Number of Phases
1 Phase
Number of Poles
2 Pole
Number of Wires
3 Wire Grounding
Operating Temperature
-40 degrees C
Size
Standard
Standard
16A 250V AC-File No. E111246,20A 250V AC-File No. 17337,20A 250V AC-File No. E1706,CSA,IEC 320,TUV,UL,VDE
Tc Connection
Screw Terminals
Temperature Rating
-40 degrees C
Type
Chassis
Voltage
250 Volt
Wattage
5000 Watt
Wire Count
3
Wire Size
16-12 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Straight Blade Inlets

General Product Info

12-Digit UPC
783585777092
Color
Black
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
Product UPC
78358577709
Weight
0.05 lb

Dimensions

Height
1.19 Inch
Length
1.47 Inch
Width
1.64 in

Certifications and Compliance

Country of Origin
USA
Features
  • Compatible with IEC320
  • Low profile
  • Impact resistant
  • Standard Product
