Milwaukee 2206-20 Fork Meter for HVAC/R

Manufacturer: Milwaukee Tool | Catalog # 2206-20 | Codale Part # 3344263
$99.00/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
The Milwaukee fork meter for HVAC/R is a heavy duty True-RMS electrical tester for professional residential, commercial and industrial applications. The 2206-20 is five tools in one providing current measurement, temperature measurement, voltage measurement, voltage detection and task lighting. In addition, the new tool provides a wide 0.63 in. fork opening, high 200 amp current range and a high contrast white-on-black display.

Technical Information

Accuracy
+/- (2% + 5 Digits) AC Amperage
Amperage
200 Amp
Applications
For Professional, Residential, Commercial and Industrial Applications
Battery Type
(AA) Alkaline
Impedance
Yes
Jaw Capacity
0.63 in
Material
Plastic
Operating Temperature
14 - 122 degrees F
Resistance
40 M?
Type
True RMS
Voltage
1000 Vac/Vdc

Manufacturer Information

Brand
Milwaukee Tool
Sub Brand
MILWAUKEE

General Product Info

12-Digit UPC
045242173747
Color
Black,Red
Product UPC
04524217374
Used With
HVAC/R is a Heavy Duty True-RMS Electrical Tester
Weight
1.1200 lb

Dimensions

Depth
3 Inch
Length
8 Inch
Warranty Length
5 Years
Features
  • Measures up to 200 A, wide 0.63 in. jaw opening
  • Wide voltage range to 1000 V AC /DC
  • True-RMS for accurate measurement in all applications
  • 600 uA DC for flame rectification
  • Built-in voltage detector and LED work light
  • Thermocouple (dual banana) input for contact temperature measurement
  • High contrast, white on black display with backlight for easy reading
  • Rugged over-molding increases durability and user grip
