Hubbell HBL11PBWL PANEL SW, SPST, PUSH w/LEADS

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL11PBWL | Codale Part # 3346858
$23.17/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page
Switches and Lighting Controls, Commercial Grade, Panel Mount and Specialty Switches, Push Button Switches, Single Pole Single Throw 4A 250V/8A 125V, Wire Leads, Black

Technical Information

Action
On/Off
Actuator
Push Button
Amperage
10 Amp
Applications
On/Off
Conductor Size
18 AWG
Contact Configuration
Two Position
Contact Rating
As Indicated
Current
10 Amp
Grade
Commercial
Horsepower
0.33 hp
Indicator
None
Interrupt Rating
4, 8, 10 AIC
Material
Non-Metal
Number of Poles
1 Pole
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
UL
Style
Wire Leads #18 AWG
Switch Type
Single Pole
Tc Connection
Wire Leads
Type
Standard, 2-Position
Voltage
250/125/120 Volt
Wattage
1000 Watt
Wire Size
18 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Panel Mount Switches

General Product Info

12-Digit UPC
783585016696
Color
Black
Product Series
Single Pole/Single Throw
Product UPC
78358501669
Weight
0.05 lb

Dimensions

Height
0.64 Inch
Length
1-1/2 Inch
Width
0.98 in

Certifications and Compliance

Country of Origin
China
Features
  • Nickel Plated for Corrosion Resistance
