PHIL 137521 MH 150W E26 CL.SLV/24

Manufacturer: Signify Lamps | Catalog # 137521 | Codale Part # 3369339
$64.50/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Installation / Instruction Manual
Philips Lighting, Metal Halide, 150W, 105V, Switch Start, Medium Screw (E26), Lumens: 12150, CRI: 82, Color Temperature: 4000K, Rated Average Life: 15,000 Hrs, Color: Cool White

Technical Information

Base
Medium Screw (E26)
Bulb Shape
ED17
Color Accuracy
65
Color Rendering Index
65
Color Temperature
4000 K
Correlated Color Temp
4,000 K
Dimmable?
No
Efficacy
90 LPW
Lumens
13,500 Lumen
Material
Ceramic
Max Voltage
105 V
Start Type
Switch Start
Type
Metal Halide
Voltage
95 Volt
Wattage
150 Watt

Manufacturer Information

Brand
Philips Lighting

General Product Info

12-Digit UPC
046677137526
Color
White
Finish
Clear
Product UPC
04667713752
Weight
0.074 kg

Dimensions

Diameter
56 mm
Features
  • Available in various bases and wattages.
  • Protective quartz shroud provides extra level of safety - shrouded arc tube for O open fixture rating.
  • No shut-off required- Ideal for 24-hours a day, 7-days a week operations (relamp fixtures at or before the end of rated life)
  • Extended eyelet mogul base will operate in both standard and exclusionary sockets.
  • Satisfies the 2005 NEC for use in open luminaires
  • BT-56 base available in 1000 watts / ED-37 base available in 360 and 400 watts / ED 28 base available in 175 and 250 watts.
  • Relamp fixtures at or before end of rated average life. The 2005 NEC states that luminaires that use a metal halide lamp shall be provided with either a containment barrier that encloses the lamp (historically referred to as an enclosed luminaire) or shall be provided with a means, typically a special lampholder, that will only accept ANSIType-O metal halide lamp. (Exceptionthis requirement will not apply to open luminaires with thick-glass parabolic reflector PAR lamps.) For more information regarding use ofType-O, S, and E metal halide systems, please refer to the NEMA white paper on this subject that is freely available at www.nema.org
Warnings
  • R \"WARNING: These lamps can cause serious skin burn and eye inflammation from short wave ultraviolet radiation if outer envelope of the lamp is broken or punctured. Do not use where people will remain for more than a few minutes unless adequate shielding or other safety precautions are used. Certain lamps that will automatically extinguish when the outer envelope is broken or punctured are commercially available.\" This lamp complies with FDA radiation performance standard 21 CFR subchapter J. (USA:21 CFR 1040.30 Canada: SOR/DORS/80-381)
  • Lamp contains mercury. Manage in Accord with Disposal Laws. See: www.lamprecycle.org or 1-800-555-0050
Applications
  • Ideal for manufacturing facilities, retail establishments and warehouses.
