Hubbell IG5352 20 Amp 125 Volt 2-Pole 3-Wire NEMA 5-20R Orange Isolated Ground Straight Blade Duplex Receptacle

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # IG5352 | Codale Part # 3369818
$12.96/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Straight Blade Devices, Receptacles, Duplex, Isolated Ground, Commercial Grade, 2-Pole 3-Wire Grounding, 20A 125V, 5-20R, Orange, Back and Side Wired, Single Pack

Technical Information

Amperage
20 Amp
Applications
Hubbell-Pro
Base Material
Nylon,Nylon
Conductor Size
14-12 AWG
Connection Type
Back and Side Wire
Contact Material
Brass
Current
20 Amp
Dielectric Strength
Withstands 2,000V minimum
Face Material
Nylon,Nylon
Flamability Class
UL 94 V-2
Grade
Commercial
Horsepower
1 hp
Material
Thermoplastic
Mounting Type
Screw
NEMA
5-20R
Number of Phases
1 Phase
Number of Poles
2 Pole
Number of Wires
3 Wire Grounding
Operating Temperature
-40 degrees C
Screw Material
Brass
Size
Standard
Standard
CSA 22.2,Fed. Spec. W-C-596,NEMA® WD-6,No. 42 File 285,UL,UL498 File No. E2186
Style
Smooth Face
Tc Connection
Back and Side Wired Terminal Screws
Type
Heavy Duty, Isolated Ground
Voltage
125 Volt
Wattage
2000 Watt
Wire Count
3
Wire Size
12-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Hubbell Pro™

General Product Info

12-Digit UPC
783585146799
Color
Orange
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
Product Series
PRO,Hubbell
Product UPC
78358514679
Weight
0.15 lb

Dimensions

Height
1.07 Inch
Length
3.28 Inch
Width
1.57 in

Certifications and Compliance

Country of Origin
China
Industry Standard(s)
  • Certified to CSA 22.2, No. 42 File 285
  • Fed. Spec. W-C-596
  • NEMA® WD-6 Compliant
  • UL Listed to UL498 File No. E2186
Performance
  • Electrical - Current Interrupting - Certified for current interrupting at full rated current
  • Electrical - Dielectric Voltage - Withstands 2,000V minimum
  • Environmental - Flammability - UL 94 V-2
  • Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact)
  • Mechanical - Product Identification - Ratings are a permanent part of the device
  • Mechanical - Terminal Accommodation - #12-#10 AWG copper stranded or solid conductor only
  • Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Features
  • Triangle marking on face indicates isolated ground
  • Slender/compact design
  • Isolated Ground
  • Smooth Face
