Blackburn CTL8-14 Compression Terminal

Manufacturer: ABB Thomas & Betts | Catalog # CTL8-14 | Codale Part # 3373151
$318.71/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
150 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet
Copper One-Hole Lug, Short Barrel, Max 35kV, 8 Str. Wire, 1/4 Bolt Size, Tin Plated, Die Color Code Red

Technical Information

Barrel Length
Short
Barrel Shape
Standard
Barrel Type
Short, Straight
Cable Size
8 AWG
Conductor Size
6 AWG
Die Color
Red
Material
Copper
Number of Holes
1 Hole
Number of Studs
1
Standard
UL E9809
Stud Size
1/4 in
Tongue Angle
Straight
Type
Non-Insulated
Voltage
35 Volt

Manufacturer Information

Brand
ABB
Sub Brand
Blackburn®

General Product Info

12-Digit UPC
783786131679
Color
Red
Finish
Tin Plated
Product UPC
78378613167
Weight
0.0100 lb

Dimensions

Height
2.3 Inch
Width
2.8 in
Notes
  • For use with copper conductor: AWG, stranded, flexible cable, welding cable and portable cord. Specially designed for inductrial and building applications.
Certifications
  • CSA
  • UL
Features
  • Color-coded for matching die identification.
  • UL Listed for AWG conductor when installed with Blackburn, Burndy, T&B or Andersons Tools.
  • Specifically chamfered barrel for ease of installation.
  • Complies with Subpart 111.60-17 of Federal Register's Coast Guard Electrical Engineering Rules and Regulations.
  • Made of high-conductivity seamless copper tubing. Tin plated for corrosion resistance.
