Milwaukee 5262-21 7/8" SDS Plus Rotary Hammer Kit

Manufacturer: Milwaukee Tool | Catalog # 5262-21 | Codale Part # 3393477
$219.00/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Get up to 40% faster drilling and 15% more life, even in the toughest applications. Designed for the toughest applications, the 1 in. SDS-Plus D-handle rotary hammer lasts longer and drills faster than other tools in its class. With a powerful 8 amp motor, it delivers 0-1, 620 RPM, 0-5,860 BPM and 2.1 ft-lbs of torque. You.ll get superior drilling speed without sacrificing the power needed to drill larger holes. At just 6.1 Lbs., this rotary hammer is easy to use and helps avoid user fatigue. A mechanical clutch protects the motor when the bit binds, and three-mode operation offers maximum versatility. The kit includes a side handle, depth rod and carrying case.

Technical Information

Amperage
8 Amp
Capacity
1 in Solid Bit, 2-1/2 in Thin Wall Core Bit
Chuck Size
1/4 in
Chuck Type
SDS Plus
Cord Length
10 ft
Cord Type
Double Insulated
Handle Type
D-Handle
Material
Metal
Max Rpm
1620 rpm
Net Weight
5.8 lb
Power Source
Corded
Torque Rating
2.1 ft lb
Type
Corded, 3-Mode
Voltage
120 Volt

Manufacturer Information

Brand
Milwaukee Tool
Sub Brand
SDS

General Product Info

12-Digit UPC
045242244539
Color
Black,Gray,Red
Housing Material
Metal Gear Box
Product UPC
04524224453
Weight
6.1 lb

Dimensions

Height
5.315 Inch
Length
18.7 Inch
Warranty Length
5 Years
Width
12.21 in
Features
  • Powerful 8 amp motor: delivers 0-1,620 RPM, 0-5,860 BPM with up to 40% faster drilling speeds than the competition
  • 2.1 Ft-lbs of torque: provides 10% faster drilling and up to 35% harder hits
  • 3-Mode operation: choose rotary hammer, hammer only and rotation only for maximum versatility
  • Mechanical clutch: protects the tool when the bit binds
  • Variable position chisel stop: allows material to be adjusted, regardless of orientation
  • Rotating brush plate: provides equal power in forward and reverse for easy removal of jammed bits, plus extends brush life
