A-B 100-D140J00 IEC 140 A MCS D Con

Manufacturer: Allen Bradley / Rockwell | Catalog # 100-D140J00 | Codale Part # 3410132
$1,207.68/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
IEC 140 A MCS D Contactor

Technical Information

Amperage
140 Amp
Coil Voltage
24 VAC at 60 Hz
Conductor Size
6 AWG-300 kcmil
Contact Configuration
0 N.O. 0 N.C.
Control Voltage
24 V
Current
140 Amp
Mounting Type
Panel
Number of Phases
3 Phase
Number of Poles
3 Pole
Power Rating
45 kW at 230 V, 78 kW at 400 V, 82 kW at 415 V, 80 kW at 500 V, 111 kW at 690 V, 75 kW at 1000 V
Standard
C-TICK,CCC
Temperature Rating
-25 to 60 degrees C
Type
MCS D, Non-Reversing
Voltage
230-1000 VAC, 24-440 VDC

Manufacturer Information

Brand
Allen-Bradley
Sub Brand
IEC

General Product Info

12-Digit UPC
781180102509
Environmental Conditions
-40 to 80 deg C Storage Temperature, IEC 60068-2-30 Climatic Withstand, 2000 NN m, per IEC60947-4 Maximum Altitude of Installation Site
Product UPC
78118010250
Weight
8.4900 lb
Features
  • Meets IEC, UL, and CSA standards requirements
  • Includes electronic and pneumatic timing modules
  • Saves energy with low power consumption
  • Available integrated PLC interface
  • Includes built-in surge suppression
  • RoHs compliant
  • Complies with RoHs
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
  • Includes space-saving coil-mounted control modules
  • Includes reversible coil terminations (line or load side)
  • Provides IP2X finger protection
  • Includes built-in surge suppression
  • Provides front and side mounting of auxiliary contacts
  • Offers common accessories for all contactor sizes
  • Provides reversible coil terminations (line or load side)
  • Meets IEC, UL, and CSA standards requirements
  • Simplifies selection with electronic wide-range AC/DC coils
