Hubbell HBL8464V VALISE Plug, HG, 20A 250V, 6-20P, WH

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL8464V | Codale Part # 3413806
$82.45/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Straight Blade Devices, Male Plug, Valise Series, Hospital Grade, Straight, 2-Pole 3-Wire Grounding, 20A 250V, 6- 20P, White, Single Pack.

Technical Information

Amperage
20 Amp
Applications
Hospitals, Heavy Duty
Conductor Size
18-12 AWG
Cord Type
All Portable
Current
20 Amp
Grade
Hospital
Grounding
Grounding
Horsepower
2 hp
Material
Composite
Mounting Type
Cord
NEMA
6-20P
Number of Poles
2 Pole
Number of Wires
3 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
C22.2 No 42 File 280C,CSA,Fed. Spec. W-C-596,NEMA® WD-6,UL,UL498 File No. E1706
Style
Valise
Tc Connection
Terminal Screws
Type
Hospital Grade
Voltage
250 Volt
Wattage
5000 Watt
Wire Count
3
Wire Size
18-12 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Valise®

General Product Info

12-Digit UPC
783585016375
Color
White
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
Product Series
Hospital Grade
Product UPC
78358501637
Weight
0.1 lb

Dimensions

Height
1.13 Inch
Length
1.88 Inch
Width
1.5 in

Certifications and Compliance

Country of Origin
USA
Features
  • Hinged one piece body design for easy assembly
  • Powerful, offsetting cord grips clamp on individual conductors
  • Standard Product
