HWDK DRUB20ACCB5 DIN-R UTL BOX, 20A

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # DRUB20ACCB5 | Codale Part # 3435671
$183.13/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Complete Unit- Duplex Receptacle with Aux Contact and 5A Circuit Breaker, DIN Rail Box, 20A Duplex, Gray.

Technical Information

Amperage
20 Amp
Applications
Unit Pre-Wired with Duplex Receptacles
Cable Entry
Terminals
Current
20 Amp
Horsepower
1 hp
Material
Composite
Mounting Type
DIN Rail/Vertical
NEMA
5-20R
Number of Poles
2-2 Pole
Number of Wires
3,3
Size
Standard Sized Product
Standard
UL
Type
1-Device, Molded and Fabricated, Standard Size
Voltage
125 Volt

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
DIN Rail Utility Box

General Product Info

12-Digit UPC
783585108162
Color
Gray
Construction
Molded And Fabricated
Product UPC
78358510816
Weight
0.1400 lb

Dimensions

Depth
64.5 mm
Height
2.54 Inch
Length
5.62 Inch
Width
3.31 in

Certifications and Compliance

Country of Origin
USA
Features
  • It provide utility power to any control cabinet
  • Optional auxiliary contacts for feed through capability
  • Pre-wired \"kits\" are available for end-user customization
  • 20A 125V, 2-Pole 3-Wire Grounding
