Hubbell USB15X2-LA USB Charger / Tamper-Resistant Receptacle, Two USB Type 2.0 Ports 3 Amp, 5VDC, 15 Amp, 125VAC Decorator Duplex - Light Almond

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # USB15X2LA | Codale Part # 3459566
$51.47/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
USB 15 A, 125V AC Charger Tamper-Resistant receptacle,Two USB Type 2.0 ports 3 Amp, 5 Volt DC

Technical Information

Amperage
15 Amp
Applications
Commercial Specification Grade
Base Material
RTP,RTP
Conductor Size
14-10 AWG
Contact Material
Plated Steel
Current
15 Amp
Face Material
RTP,RTP
Flamability Class
UL 94V-2
Horsepower
0.5 hp
Material
Thermoplastic
Mounting Type
Flush, Screw
Number of Outlets
2
Number of Phases
1 Phase
Number of Poles
2 Pole
Number of Wires
3 Wire
Screw Material
Plated Steel
Size
Standard Sized Product
Tamper Resistant?
Yes
Tc Connection
Back and Side Wired Screw Terminals
Type
Decorator Duplex
Voltage
125 Volt
Wattage
1875 Watt
Wire Count
3
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Straight Blade Devices

General Product Info

12-Digit UPC
883778304613
Color
Almond
Product UPC
88377830461
Weight
0.3600 lb

Dimensions

Height
1.96 Inch
Length
4.12 Inch
Width
1.75 in

Certifications and Compliance

Country of Origin
China
Performance
  • Electrical - Current Interrupting - Certified for current interrupting at full rated current
  • Electrical - Dielectric Voltage - Withstands 2,000V minimum
  • Environmental - Flammability - UL 94V-2
  • Environmental - Operating Temperature - Maximum continuous 75°C, minimum -40°C (w/o impact)
  • Mechanical - Product Identification - Ratings are a permanent part of the device
  • Mechanical - Terminal Accommodation - #14-#10 AWG copper stranded or solid conductor only
  • Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
  • Mechanical - USB Port - Stainless steel Rated for 10,000 plug insertions and removal
Overview
  • Straight Blade Devices, Receptacles, Duplex, Dual USB Type 2.0 ports 3.8 Amp, 5 Volt DC, 15A 125V, 2-Pole 3-Wire Grounding, 5-15R, Light Almond
  • Compatible with USB 1.1/2.0/3.0 devices, including Apple® products
  • Green LED indicator to show USB power available
  • Dual USB Charger, Tamper Resistant
  • Tamper-Resistant decorator duplex receptacle
  • Two USB ports 3.8 Amp, 5V DC, type A, class 2.0
