Panduit PV14-10FX-C Pan-Term® Vinyl Expanded Insulation Ring Terminal

Manufacturer: PANDUIT | Catalog # PV14-10FX-C | Codale Part # 3461075
$229.87/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Buy American Compliant Buy American Compliant Primary Spec Sheet Product Catalog Page
Fork Terminal, vinyl insulated, 16- 14 AWG, #10 stud size, expanded insulation for large wire O.D.

Technical Information

Barrel Length
0.48 in
Barrel Type
Funnel
Color Coding
Blue
Conductor Size
14 AWG
Enclosure
Fork shape
Material
Copper
Max Operating Temperature
105 degrees C
Min Operating Temperature
167 degrees F
Size
10 in
Standard
CSA,E2186,UL
Tc Connection
Funnel Entry
Temperature Rating
221 degrees F
Tongue Thickness
0.03 in
Tongue Width
0.34 in
Type
Bell End
Voltage
600 Volt
Wire Size
18-14 AWG

Packaging

Pkg Qty
100

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
Pan-Term®

General Product Info

12-Digit UPC
074983804283
Color
Olive, Orange, Royal Blue and Yellow
Finish
Rust-Proof Plating, Vinyl Coated
Product UPC
07498380428
UNSPSC
39121409
Weight
0.0030 lb

Dimensions

Overall Length
0.97 in
Width
8.6 mm

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
Mexico
Standards and Certifications
  • Standards Met: UL Listed 587H E52164; CSA Certified LR31212
