Burndy ASA1000U Terminal Stacking Adaptor, 1000 kcmil, UL Listed 90 Deg C,600 Volts to 35 kV

Manufacturer: Hubbell-Burndy | Catalog # ASA1000U | Codale Part # 3463891
$26.47/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Terminal Stacking Adaptor, 1000 kcmil, UL Listed 90 C,600 Volts to 35 kV

Technical Information

Applications
For Aluminum And Copper Terminals
Conductor Size
1000 kcmil
Direct Burial?
No
Material
Aluminum
Plated?
Yes
Plating Type
Tin
Temperature Rating
194degrees F
Type
Stacking Adapters
Voltage
35,000 Volt

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Burndy

General Product Info

12-Digit UPC
781810521045
Finish
Tin Plated
Product UPC
78181052104
Weight
0.3000 lb

Dimensions

Height
1-1/4 Inch
Length
0.91 Inch
Overall Length
23 mm
Pad Width
1.25 in
Width
1.25 in

Certifications and Compliance

Country of Origin
USA
CSA
Yes
Features
  • For use on terminals made from copper or aluminum
  • May be used with standard NEMA two and four hole terminals
  • TO stack four hole NEMA terminations use two stacking adapters assembled side-by-side
  • Only three sizes necessary to accommodate terminals from 250 kcmil through 1000 kcmil
