Hubbell USB20X2-GY USB Charger / Tamper-Resistant Receptacle, Two USB Type 2.0 Ports 3 Amp, 5VDC, 20 Amp, 125VAC Decorator Duplex - Gray

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # USB20X2GY | Codale Part # 3471416
$56.32/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
USB 20A 125V AC Charger Tamper-Resistant receptacle,Two USB Type 2.0 ports 3 Amp, 5 Volt DC

Technical Information

Amperage
20 Amp
Applications
Commercial Specification Grade
Base Material
RTP,RTP
Conductor Size
14-10 AWG
Contact Material
Plated Steel
Face Material
RTP
Flamability Class
UL 94V-2
Material
Thermoplastic
Number of Poles
2 Pole
Number of Wires
3 Wire
Screw Material
Plated Steel
Size
Standard Sized Product
Standard
ANSI C-73
Tamper Resistant?
Yes
Tc Connection
Back and Side Wired Terminal Screws
Type
Decorator, Tamper-Resistant
Voltage
2,000 Volt
Wattage
2500 Watt
Wire Count
3
Wire Size
14-12 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Straight Blade

General Product Info

12-Digit UPC
883778304897
Color
Gray
Product UPC
88377830489
Weight
0.3000 lb
Features
  • Two USB ports 3.8 Amp, 5V DC, type A, class 2.0
  • Tamper-Resistant decorator duplex receptacle
  • Green LED indicator to show USB power available
  • Compatible with USB 1.1/2.0/3.0 devices, including Apple® products
Listings
  • cULus listed to UL498
