Panduit FLCSMBLY Field Polish LC Connector, Simplex, 50?m Multimode, 1.6mm Black Boot

Manufacturer: PANDUIT | Catalog # FLCSMBLY | Codale Part # 3473590
$59.53/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Buy American Compliant Buy American Compliant Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
The simplex field polish LC Fiber Optic Connector is intended for installation onto multimode 50/125?m, 1.6mm jacketed fiber. The LC connector has a black body with a black 1.6mm boot.

Technical Information

Applications
Used for Equipment Cross-Connects or Interconnects in Backbone, Horizontal and Work Area Applications for High-Speed Data Transmissions
Body Type
Simplex
Boot Color
Black
Connection Type
LC
Connector Type
Field Polished LC
Fiber Cable Size
nm
Fiber Type
OM2/OM3/OM4 50/125 m Multimode, 900 m
Material
Plastic
Max Operating Temperature
140 degrees F
Min Operating Temperature
0 degrees C
Tc Connection
LC
Temperature Rating
32 - 140 degrees F
Type
Simplex, Pot and Polish Style, Tight-Buffered

Packaging

Pkg Qty
1

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
FiberRunner

General Product Info

12-Digit UPC
074983127177
Color
Black
Product UPC
07498312717
UNSPSC
43223310
Weight
0.0100 lb

Dimensions

Outer Diameter
0.08 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
Costa Rica
Standards and Certifications
  • Standards Met: TIA/EIA-604 FOCIS-10 compatible; exceeds TIA/EIA-568-B.3 requirements
