Hubbell USB8300-LA USB Charger / Tamper-Resistant Hospital-Grade Receptacle, Two USB Type 2.0 Ports 3 Amp, 5 Volt DC, 20 Amp, 125 Volt AC Decorator Duplex, Light Almond

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # USB8300LA | Codale Part # 3493606
$51.70/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
USB 20A 125V AC Charger Tamper-Resistant receptacle, Two USB Type 2.0 ports 3 Amp, 5 Volt DC

Technical Information

Amperage
20 Amp
Base Material
RTP,RTP
Conductor Size
14-10 AWG
Connection Type
Back and Side
Contact Material
Brass
Face Material
RTP
Flamability Class
UL 94V-2
Grade
Hospital
Material
Nylon
Mounting Type
Flush
NEMA
5-20R
Number of Poles
2 Pole
Number of Wires
3 Wire
Screw Material
Plated Steel
Tamper Resistant?
Yes
Temperature Rating
-40 to 75 degrees C Continuous
Type
Tamper-Resistant, Decorator
Voltage
2,000 Volt
Wire Count
3

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems

General Product Info

12-Digit UPC
883778305061
Color
Light Almond
Environmental Conditions
UL 94-V2 Flammability Rating
Product UPC
88377830506
Weight
0.3500 lb
Features
  • Two USB ports 3.8 Amp, 5V DC, type A, class 2.0
  • Tamper-Resistant decorator duplex receptacle
  • Green LED indicator to show USB power available
  • Compatible with USB 1.1/2.0/3.0 devices, including Apple® products
Listings
  • cULus listed to UL498 and UL1310 Hospital Grade
  • NEMA® WD-6 Compliant
