Hubbell HBL7557G Locking Flanged-Receptacle, 2P3W, 10A 250V/15A125V

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL7557G | Codale Part # 3499675
$70.28/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page
Locking Devices, Twist-Lock®, Industrial, Stainless Steel Flanged Receptacle, 10A 250/15A 125V, 2-Pole 3-Wire Grounding, Non-NEMA, Screw Terminal, Brown/Stainless.

Technical Information

Amperage
15 Amp
Applications
Heavy Duty Industrial
Conductor Size
14 AWG
Current
10 Amp
Dielectric Strength
Withstands 2,000V minimum
Grade
Industrial
Material
Thermoplastic
Mounting Type
Screw
Number of Phases
1 Phase
Number of Poles
2 Pole
Number of Wires
3 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
CSA C22.2 No.42,Fed. Spec. W-C-596,UL 498
Tc Connection
Screw Terminal
Type
Single, Metallic Flange
Voltage
250/125 Volt
Wattage
3750 Watt
Wire Count
3
Wire Size
18-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock®

General Product Info

12-Digit UPC
783585237671
Color
Black
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Product UPC
78358523767
Weight
0.15 lb

Dimensions

Height
1.32 Inch
Length
2.31 Inch
Width
1.75 in

Certifications and Compliance

Country of Origin
Puerto Rico
Features
  • Heat resistant thermoset construction
  • Stainless steel casing
  • #8-32 terminal screws
  • Mounting screws included
  • Metallic Flange
