Hubbell HBL7557 10 Amp 250 VAC 3-Pole 3-Wire Non-NEMA Stainless Steel Flanged Receptacle

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL7557 | Codale Part # 3499676
$131.62/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page
Locking Devices, Twist-Lock®, Industrial, Stainless Steel Flanged Receptacle, 10A 250V/15A 125V, 3-Pole 3-Wire Non Grounding, Non- NEMA, Screw Terminal, Brown/Stainless.

Technical Information

Amperage
15 Amp
Applications
Heavy Duty Industrial
Conductor Size
14 AWG
Connection Type
Screw Terminal
Current
10 Amp
Dielectric Strength
Withstands 2,000V minimum
Material
Composite
Number of Conductors
3
Number of Phases
1 Phase
Number of Poles
3-3 Pole
Number of Wires
3,3
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
CSA C22.2 No.42,Fed. Spec. W-C-596,UL 498
Tc Connection
Screw Terminal
Type
Standard, Single, 3-Pole
Voltage
250/125 Volt
Wattage
3750 Watt
Wire Count
3
Wire Size
18-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock®

General Product Info

12-Digit UPC
783585237664
Color
Black
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Product UPC
78358523766
Weight
0.15 lb

Dimensions

Height
1.32 Inch
Length
2.31 Inch
Width
1.75 in

Certifications and Compliance

Country of Origin
Puerto Rico
Features
  • Heat resistant thermoset construction
  • Stainless steel casing
  • #8-32 terminal screws
  • Mounting screws included
  • Metallic Flange
