Hubbell RR450 50 Amp 125/250 Volt 3-Pole 4-Wire NEMA 14-50R Black Range and Dryer Power Receptacle

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # RR450 | Codale Part # 3508931
$12.96/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
TradeSelect, Straight Blade Devices, Residential Grade, Receptacles, Single, 50A 125/250V, 3-Pole 4-Wire Grounding, 14-50R, Surface Mount, Black

Technical Information

Amperage
50 Amp
Applications
Residential Range and Dryer Devices
Conductor Size
6 AWG
Current
50 Amp
Grade
Residential
Material
Thermoplastic
Mounting Type
Screw, Surface
NEMA
14-50R
Number of Phases
1 Phase
Number of Poles
3 Pole
Number of Wires
4 Wire
Size
Standard Sized
Standard
UL
Tc Connection
Pressure Screw Terminals
Type
Single Receptacle
Voltage
125/250 Volt
Wattage
12500 Watt
Wire Size
6 AWG

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Trade-Select™

General Product Info

12-Digit UPC
883778100833
Color
Black
Product Series
Heavy Duty
Product UPC
88377810083
Weight
0.8300 lb

Dimensions

Height
1.9 Inch
Length
5.9 Inch
Width
2.5 in

Certifications and Compliance

Country of Origin
China
Features
  • Flush Mount for 1- or 2-Gang Box
  • Residential Range and Dryer Receptacle
  • Surface Mount Receptacle
