HWDK HBL5260WSA DUP SPD RCPT, 15A 1

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL5260WSA | Codale Part # 3518514
$123.02/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Surge Protective Devices, SPIKESHIELD TVSS Duplex Receptacle with Light, 15A 125V, 5-15R, White

Technical Information

Amperage
15 Amp
Applications
Decorator Duplex
Current
15 Amp
Frequency
60 Hz
Material
Composite
NEMA
5-15R
Number of Phases
1 Phase
Operating Temperature
0 To 60 degrees C
Response Time
5
Size
Standard Sized Product
Standard
C22.2 No. 42,CSA,File E2186,UL,UL Standards 498
Tc Connection
Terminals
Type
Non-Reversing
Voltage
125 Volt

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Surge Supression Devices

General Product Info

12-Digit UPC
783585219905
Color
White
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Product Series
Specification Grade
Product UPC
78358521990
Weight
0.3000 lb

Dimensions

Height
2 Inch
Length
4.3 Inch
Width
2.2 in

Certifications and Compliance

Country of Origin
China
Features
  • Automatic self-grounding staple
  • Distinctive surge symbol provides quick identification
  • Power-on indicator light verifies that power is available
  • Alert alarm sounds when surge protection is no longer functioning
  • Standard Product
