Burndy YH2C2CWCC Copper Compression H Tap, Tin Plated, wire sizes - Run (Main): #2-#2 Class B,C, #2-#6 Class B,C, #2-#6 Class G,H,I,DLO, #8 Class I, DLO, Tap 1: #2-#2 Class B,C, #2-#6 Class B,C, #2-#6 Class G,H,I,DLO, #8 Class I, DLO, Tap 2: #8-#14 Class B,C, #8-#14 Class G,H,I,DLO, #8 Class K Class I, DLO, Tap 3: #8-#14 Class B,C, #8-#14 Class G,H,I,DLO, #8 Class K, kitted w/ clear cover

Manufacturer: Hubbell-Burndy | Catalog # YH2C2CWCC | Codale Part # 3531936
$44.63/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Buy American Compliant Buy American Compliant Primary Spec Sheet
Copper Compression H Tap w/ Clear Flame Retardant Cover, 2-6 AWG (Main & Tap 1), 8-14 AWG (Tap 2 & Tap 3), Tin Plated

Technical Information

Applications
For Used To Accommodates A Wide Range Of Run/Tap Copper Cable Combinations Including Both Flexible And Code Combinations
Color Coding
Brown
Conductor Material
COPPER
Conductor Size
8-2 AWG
Connection Type
CLR COVER,H-TAP W
Material
Copper
Max Voltage
35000 V
Plated?
Yes
Plating Type
Tin - Electro Plated
Size
1.25 IN Height X 0.6 IN Width X 0.75 IN Length
Tap Size
2, 4, 6, 8, 12, 10, 14 AWG
Temperature Rating
194
Type
Compression Taps

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Burndy

General Product Info

12-Digit UPC
781810436455
Finish
Tin-Plated,Tin-Plated
Product UPC
78181043645
Weight
0.1900 lb

Dimensions

Height
1-1/4 Inch
Length
3/4 Inch
Overall Length
19 mm
Width
0.60 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
CSA
Yes
Features
  • Uninsulated compression H-tap connector, tin-plated
  • Designs with more than one tap wire groove require installers to utilize a minimum of one Main (Run) and one Tap groove, other grooves can be left empty
  • 'Third Hand' is a string provided with the H-tap connector and is used to wrap the wire while being inserted into the run and tap grooves
  • H-tap connectors can be purchased separately or kitted with covers
  • YH is connector sold separately without cover
  • YH-WC is kitted H-tap connector and black cover
  • YH-WCC is kitted H-tap connector and clear cover
