CRS-H EDSC3140 EDS FS GENERAL USE S

Manufacturer: Eaton Crouse-Hinds | Catalog # EDSC3140 | Codale Part # 3535874
$1,519.90/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page
Eaton Crouse-Hinds series EDS snap switch control station, 20A, With switch, With two 1" hubs, Feraloy iron alloy, 1, Single-gang, Four-pole, 2, 120-277V, Through Feed, 4-way, 1", 120-277 Vac

Technical Information

Amperage
20 Amp
Applications
Chemical Plants, Oil and Gas Refineries, Paint and Varnish Manufacturing Plants, Gasoline Bulk Loading, Terminals, Grain Elevators, Grain Processin
Enclosure
Class I Div 1 2 Group C D,Class II Div 1 Group E F G,Class II Div 2 Group F G,Class III,NEMA 3,NEMA 7B,NEMA 7C,NEMA 7D,NEMA 9E,NEMA 9F,NEMA 9G
Material
Iron
Number of Poles
4 Pole
Size
5-7/8 In Length X 3-1/2 In Width X 3-1/16 In Height
Standard
CSA C22.2,UL 1203
Type
Factory Sealed,Front Operated,Snap Switch,Through Feed
Voltage
120-277 Volt

Manufacturer Information

Brand
Crouse-Hinds
Sub Brand
FlexStation

General Product Info

12-Digit UPC
782274765907
Product UPC
78227476590
Weight
7.9 lb

Dimensions

Height
5-7/8 Inch
Length
5.06 Inch
