Hubbell HBL22CM427H/LOCK Receptacle Flanged MTG, 3P4W, 30A 600V

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL22CM427 | Codale Part # 3537321
$1,188.80/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Locking Devices, Hubbellock®, Industrial, Receptacle, 30A 600V AC, 20A 250V DC, 3-Pole 4-Wire Grounding, Non-NEMA, Weathertight, corrosion resistant, nickel plated brass plate, Screw Terminal, FS/FD Box Mounting, Metallic

Technical Information

Amperage
30 Amp
Applications
Heavy Duty Industrial
Conductor Size
12-10 AWG
Current
20 Amp
Dielectric Strength
Withstands 2,000V minimum
Grade
Industrial
Material
Thermoplastic
Mounting Type
Screw, Flush, Inner Lying
Number of Poles
3 Pole
Number of Wires
4 Wire
Operating Temperature
-40 degrees C
Size
4.5 in x 3.5 in x 3.62 in
Standard
CSA Standard,UL Standard
Tc Connection
Screw Terminal
Type
Heavy Duty
Voltage
250 Volt
Wattage
18000 Watt
Wire Count
4
Wire Size
10-6 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Hubbell-Lock®

General Product Info

12-Digit UPC
783585017365
Color
Black
Environmental Conditions
Corrosion-Resistant
Product UPC
78358501736
Weight
2.3 lb

Dimensions

Height
3.62 Inch
Length
4-1/2 Inch
Width
3.5 in

Certifications and Compliance

Country of Origin
Puerto Rico
Features
  • Spring loaded safety shutter contains arcing when mating or un-mating devices under load
  • Spring loaded safety shutter automatically ejects the plug eliminating contact teasing
  • Box terminals in conjunction with screws with pressure pads provide maximum termination strength and dependability
  • Nickel plated cover and closure cap provides protection from moisture and dust
  • Auto Ejects Improperly Made Connection, Corrosion Resistant
