Hubbell HBL45935 Locking Connector, VARILOAD, 4P5W, 20A 120/208V

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL45935 | Codale Part # 3543638
$715.36/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Locking Devices, Twist-Lock®, Variload®, Female Connector Body, 20A 3-Phase Wye 120/208V AC only - 400Hz, 4-Pole 5-Wire Grounding, Non-NEMA, Screw Terminal, Black Non Metallic Body, Unique Center Pin.

Technical Information

Amperage
20 Amp
Applications
For Heavy Duty Applications
Conductor Size
14-10 AWG
Cord Size
0.35 - 1.15 in
Current
20 Amp
Dielectric Strength
2500 VAC
Grounding
Grounding
Material
Composite
Mounting Type
Cord
Number of Conductors
5-Wire Grounding
Number of Phases
3 Phase
Number of Poles
4 Pole
Number of Wires
4 Wire
Operating Temperature
-40 degrees C
Size
Standard
Standard
UL 498
Tc Connection
Pressure Screw Terminal
Temperature Rating
-40 to 75 degrees F
Type
Standard
Voltage
120/208 Volt
Wire Count
5
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock®, Variload®

General Product Info

12-Digit UPC
783585238159
Color
Black
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Product UPC
78358523815
Weight
0.5 lb

Dimensions

Height
3.79 Inch
Length
2.13 Inch
Width
2.13 in

Certifications and Compliance

Country of Origin
USA
Features
  • Heat resistant thermoset construction
  • Non-interchangable center pin configuration to be designated to different circuits
  • Unique Center Pin
