LEV DSM10-1LZ W/I/LA DEC SL DIM 100

Manufacturer: Leviton | Catalog # DSM10-1LZ | Codale Part # 3558544
$88.11/ea
ea
Log in or register to view your price, purchase history, and more!
11 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet MDM Safety Data Sheet
Universal Decora Dimmable LED, CFL, MLV and Incandescent Rocker- Slide Dimmer, 1000W-120VAC Incandescent, 1000VA-120VAC MLV, 450W-120VAC Dimmable LED and CFL, 60Hz, Single Pole or 3-Way - White, Ivory & Light Almond

Technical Information

Action
Slide Bar For Lighting Level Control,Switch
Applications
For Residential/Commercial use
Frequency
60 Hz
Number of Poles
3 Pole
Power Rating
1000 W Incandescent, 450 W LED/CFL
Standard
NOM,cCSAus
Style
Decora
Switch Type
3-Way,Single-Pole
Type
Slide Handle
Voltage
120 Volt
Wattage
1000 Watt

Manufacturer Information

Brand
Leviton
Sub Brand
Decora Slide and Digital Dimm

General Product Info

12-Digit UPC
078477692332
Color
Ivory,Light Almond,White
Product UPC
07847769233
Weight
0.4340 lb

Dimensions

Warranty Length
5 yr

Certifications and Compliance

Country of Origin
China
Patents
  • MX321054
  • US8664886
  • US9431192
  • US9543667
  • US9681526
  • US9974152
Features
  • New aesthetically pleasing design with rocker switch and slender dimmer control slide bar
  • Integrated linear full-range slide control for easy, precise operation
  • Controls a variety of dimmable LED and CFL lamps
  • Compatible with Magnetic Low Voltage loads, Incandescent and Halogen lamps
  • Single pole or 3-way operation (when using 3-way switch); packaged with White, Ivory, and Light Almond color change kits
  • Additional color change kits available in Black, Brown, Red and Gray
  • Slim, compact housing fits easily into a standard wallbox and is suitable for multi-gang installations with other Decora products
  • The slide bar location preserves the selected brightness level when the dimmer is switched OFF
  • Microprocessor control offers flexibility to program LEDs and CFLs for best performance
  • Switch under the color change kit to turn locator light ON/OFF
  • No fins for multi-gang installation
  • Wired using leads, a Neutral wire is not required for operation
  • Built-in radio/TV interference filter
  • Leviton Decora Rocker-Slide Universal Dimmers provide smooth, slide-action, full-range dimming for Incandescent, Magnetic Low Voltage, dimmable LEDs and dimmable CFL loads. They combine a Decora rocker switch with a contemporary full-range slender slide bar for precise lighting control. With a new, streamlined style, Decora dimmers and fan speed control complement any interior design and are compatible with other Decora devices.
