Hubbell GFTWRST20W 20 Amp 125 Volt 2-Pole 3-Wire NEMA 5-20R White GFCI Receptacle

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # GFTWRST20W | Codale Part # 3577922
$27.36/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Power Protection Devices, Receptacle, Self Test, GFCI, TRWR, Commercial Grade, 20A 125V, 2-Pole 3-Wire Grounding, 5-20R, White Almond

Technical Information

Amperage
20 Amp
Applications
Commercial Grade
Conductor Size
14-12 AWG
Current
20 Amp
Grade
Commercial
Material
Thermoplastic
Mounting Type
Screw
NEMA
5-20R
Number of Poles
2 Pole
Number of Wires
3 Wire Grounding
Size
Standard
Standard
NEC®
Style
Standard
Tc Connection
Terminal Screws
Type
Straight Blade, Decorator, Self-Test, Tamper-Resistant and Weather Resistant
Voltage
125 VAC
Wattage
2500 Watt
Wire Size
14-12 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Straight Blade GFCI Receptacles

General Product Info

12-Digit UPC
883778122712
Color
White
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
Product Series
Heavy Duty
Product UPC
88377812271
Weight
0.3500 lb

Dimensions

Height
7.044 Inch
Length
5.048 Inch
Width
2.048 in

Certifications and Compliance

Country of Origin
China
Features
  • Patented shutter design for tamper-resistant protection
  • Meets NEC requirements for TR (517-18c) and WR (406.9), UV and corrosion resistance for harsh and damp applications
  • Patented AUTOGUARD® self test technology
  • Protects against line and load reversal, no power to the face or downstream if device is miswired
