Hubbell HBLDS6SSR 60 Amp Stainless Steel Unfused Disconnect Switch Enclosure

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBLDS6SSR | Codale Part # 3581527
$1,785.07/ea
ea
Log in or register to view your price, purchase history, and more!
1 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Disconnect Switches, Sloped Enclosure, 60A 600V AC, Non-Fused, NEMA 4X, Stainless Steel

Technical Information

Amperage
60 Amp
Applications
For Motor Starting without Overload Protection
Connection Type
Pressure Screw
Current
60 Amp
Enclosure Rating
4X, IP69K
Enclosure Type
Type 4X, IP69k
Load Rating
36000 W
Mounting Type
Screw
Number of Phases
3 Phase
Number of Poles
3 Pole
Operating Temperature
-40 degrees C
Power Rating
36,000 W
Size
11.41 in x 7.66 in x 6.1 in
Style
Heavy Duty
Tc Connection
Pressure Screw Terminals
Temperature Rating
-40 degrees C
Type
Standard, Unfused, Sloped Top
Voltage
600 Volt

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Motor Disconnects

General Product Info

12-Digit UPC
783585541600
Housing Material
Stainless Steel
Product Series
Non-Fused
Product UPC
78358554160
Shape
Sloped Top
Weight
11.2500 lb

Dimensions

Height
6.1 Inch
Length
11.41 Inch
Width
7.66 in

Certifications and Compliance

Country of Origin
Poland
Features
  • Formed in nonporous 304 stainless steel
  • IP69k and Type 4X,12K water ingress protection
  • Certified by NSF for hygiene in food processing applications
  • Highly visible red handle which meets OSHA Lockout/Tagout capabilities
  • Accepts up to 2 Auxiliary contacts
