Hubbell DRUBGFI20ACDIN-R UTL BOX, 20A 125V, DUP, GFCI, w/AC, GY

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # DRUBGFI20AC | Codale Part # 3595395
$239.63/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
DIN Rail Utility Box, Complete Unit- GFCI, with Aux Contact, DIN Rail Box, 20A GFCI, Gray.

Technical Information

Amperage
20 Amp
Applications
Unit Pre-Wired with GFCI Duplex
Cable Entry
Terminals
Current
20 Amp
GFCI
Yes
Grounding
Neutral and Ground
Horsepower
1 hp
Material
Composite
Mounting Type
35 mm DIN Rail/Vertical
NEMA
5-20R
Number of Poles
2 Pole
Number of Wires
3 Wire
Size
Standard Sized Product
Standard
UL
Type
Complete Unit
Voltage
125 Volt

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
DIN Rail Utility Box

General Product Info

12-Digit UPC
783585108186
Color
Gray
Construction
Molded And Fabricated
Product UPC
78358510818
Weight
0.1400 lb

Dimensions

Height
2.54 Inch
Length
5.62 Inch
Width
3.31 in

Certifications and Compliance

Country of Origin
USA
Features
  • It provide utility power to any control cabinet
  • Optional auxiliary contacts for feed through capability
  • Pre-wired \"kits\" are available for end-user customization
  • 20A 125V, 2-Pole 3-Wire Grounding
