A-B 100-D180ED00 IEC 180 A MCS D Co

Manufacturer: Allen Bradley / Rockwell | Catalog # 100-D180ED00 | Codale Part # 3612693
$2,001.48/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
IEC 180 A MCS D Contactor

Technical Information

Amperage
180 Amp
Coil Voltage
110 - 130 VAC at 50/60 Hz
Conductor Size
6 AWG-300 kcmil
Contact Configuration
0 N.O. 0 N.C.
Control Voltage
110/130 V
Current
180 Amp
Number of Phases
3 Phase
Number of Poles
3 Pole
Power Rating
55 kW at 230 V, 90 kW at 400 V, 90 kW at 415 V, 110 kW at 500 V, 90 kW at 690 V, 132 kW at 1000 V, 110 kW at 200 V
Standard
C-TICK,KC
Temperature Rating
-25 to 60 degrees C
Type
Non-Reversing
Voltage
600 Volt

Manufacturer Information

Brand
Allen-Bradley
Sub Brand
IEC

General Product Info

12-Digit UPC
781180103384
Environmental Conditions
-40 to 80 C Storage, IEC 60068-2-27 Resistance to Shock, IEC 60068-2-6 Resistance to Vibration, 2000 NN Per IEC 60947-4 Maximum Altitude Of Installation Site, IEC 60068-2-30 Climatic Withstand
Product UPC
78118010338
Weight
9.4200 lb
Features
  • Includes electronic and pneumatic timing modules
  • Includes reversible coil terminations (line or load side)
  • Includes built-in surge suppression
  • Saves energy with low power consumption
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
  • Provides front and side mounting of auxiliary contacts
  • Provides IP2X finger protection
  • RoHs compliant
  • Meets IEC, UL, and CSA standards requirements
  • Meets IEC, UL, and CSA standards requirements
  • Includes space-saving coil-mounted control modules
  • Available integrated PLC interface
  • Includes built-in surge suppression
  • Complies with RoHs
  • Provides reversible coil terminations (line or load side)
  • Offers common accessories for all contactor sizes
  • Simplifies selection with electronic wide-range AC/DC coils
