Product image for Allen Bradley 700-HLT2U12 GP Terminal Block Relay
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Allen Bradley 700-HLT2U12 GP Terminal Block Relay

Manufacturer: Allen Bradley / Rockwell | Catalog # 700-HLT2U12 | Codale Part # 3714658
$42.17/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
12 V AC/DC GP Terminal Block Relay

Technical Information

Amperage
6 Amp
Applications
Electromechanical Relay Output
Coil Voltage
12 V
Connection Type
Spring Clamp
Contact Configuration
SPST - 1 NO
Contact Material
Silver
Contact Rating
30 A at 24 VAC, 120 VAC, 15 A at 240 VAC, 6 mA at 12 V (Silver), 2.5 mA at 8 V (Gold)
Contact Type
Standard Silver Contacts
Number of Poles
1 Pole
Operating Cycles
10000000 Mechanical, 100000 Electrical
Resistance
2 k?
Tc Connection
Spring Clamp
Temperature Rating
-40 to 55 degrees C
Type
Single Contact
Voltage
12 VAC/VDC

Manufacturer Information

Brand
Allen-Bradley

General Product Info

12-Digit UPC
611320760873
Product UPC
61132076087
Weight
0.0840 lb
Features
  • Offers timing range from 0.1 sec...6 hr
  • Provides four timing functions
  • Offers externally replaceable relay modules
  • Offers leakage current suppression version
  • Provides built-in retainer clip and snap-in marker lever
  • Includes standard status indicator, reverse polarity protection and surge protection
  • Includes externally replaceable relay modules
  • Includes screw terminal bases
  • Includes built-in retainer clip and snap-in marker lever
  • Includes screw-type and spring-clamp terminal bases
  • Includes relay and socket assembled interface modules for high density interposing or isolation applications
  • Includes SPDT (relay)
  • Provides standard status indicator, reverse polarity protection, and surge protection
