Product image for Allen Bradley 100-D210EA11 IEC 210 A MCS D Contactor
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Image thumbnail 3
Email

Allen Bradley 100-D210EA11 IEC 210 A MCS D Contactor

Manufacturer: Allen Bradley / Rockwell | Catalog # 100-D210EA11 | Codale Part # 3826693
$2,132.48/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
IEC 210 A MCS D Contactor

Technical Information

Amperage
210 Amp
Coil Voltage
208 - 277 VAC at 50/60 Hz
Conductor Size
4 AWG-350 kcmil
Contact Configuration
1 NO, 1 NC Auxiliary
Control Voltage
208/277 V
Current
210 Amp
Number of Phases
3 Phase
Number of Poles
3 Pole
Power Rating
63 kW at 230 V, 118 kW at 400 V, 125 kW at 415 V, 205 kW at 500 V, 200 kW at 690 V, 110 kW at 1000 V, 60 kW at 200 V
Standard
C-TICK,CE,CSA,CUL,KC,UL
Temperature Rating
-25 to 60 degrees C
Type
Non-Reversing
Voltage
600 Volt

Manufacturer Information

Brand
Allen-Bradley
Sub Brand
IEC

General Product Info

12-Digit UPC
781180104664
Environmental Conditions
-40 to 80 C Storage, IEC 60068-2-27 Resistance to Shock, IEC 60068-2-6 Resistance to Vibration, 2000 NN Per IEC 60947-4 Maximum Altitude Of Installation Site, IEC 60068-2-30 Climatic Withstand
Product UPC
78118010466
Weight
18.7000 lb
Features
  • Available integrated PLC interface
  • Provides IP2X finger protection
  • Provides front and side mounting of auxiliary contacts
  • Includes reversible coil terminations (line or load side)
  • Includes built-in surge suppression
  • Includes electronic and pneumatic timing modules
  • Offers common accessories for all contactor sizes
  • Saves energy with low power consumption
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
  • RoHs compliant
  • Meets IEC, UL, and CSA standards requirements
  • Complies with RoHs
  • Includes space-saving coil-mounted control modules
  • Provides reversible coil terminations (line or load side)
  • Simplifies selection with electronic wide-range AC/DC coils
  • Includes built-in surge suppression
  • Meets IEC, UL, and CSA standards requirements
