Siemens GF322N 240 VAC/250 VDC 60 Amp 3-Pole 4-Wire NEMA 1 General Duty Fusible Safety Switch

Manufacturer: Siemens | Catalog # GF322N | Codale Part # 400995
$124.63/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
60A 3P 240V 4W FUSED GD TYPE 1

Technical Information

Action
SINGLE THROW
Actuator
SINGLETHROW
Ambient Temperature
-29 degrees C
Amperage
60 Amp
Applications
DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS
Enclosure
NEMA1
Frequency
60 Hz
Insulated?
No
Material
Steel
Mounting Type
2 or 3 Point Mounting Holes
NEMA Size
1
Net Weight
12,236 lb
Number of Poles
3 Pole
Number of Wires
4 Wire
Operating Cycles
10000
Operating Temperature
-20 To 120 degrees F
Standard
UL
Tc Connection
MECHANICALLUGS
Type
Fusible
Voltage
240 Volt
Wattage
4 Watt

Manufacturer Information

Brand
Siemens
Sub Brand
VBII

General Product Info

12-Digit UPC
783643148130
Product UPC
78364314813

Certifications and Compliance

Country of Origin
Mexico
