Allen-Bradley 801-FSC148 Slow Action Weight Spring Return Type 17 Housing Style General Purpose Limit Switch

Manufacturer: Allen Bradley / Rockwell | Catalog # 801-FSC148 | Codale Part # 4066290
$7,491.79/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
General Purpose Limit Switch

Technical Information

Action
Spring Return
Actuator
Weight Lever
Amperage
3 Amp at 120 VAC, 1.5 Amp at 240 VAC, 0.75 Amp at 480 VAC, 0.6 Amp at 600 VAC, 1.1 Amp at 115 VDC, 0.55 Amp at 230 VDC, 0.2 Amp at 550 VDC
Contact Configuration
1 NO, 1 NC
Enclosure
NEMA 17 Housing Style
Standard
KC
Temperature Rating
0 degrees C to 40 degrees C
Type
General Purpose
Voltage
120-600 VAC, 115-550 VDC

Manufacturer Information

Brand
Allen-Bradley

General Product Info

12-Digit UPC
781180781490
Product UPC
78118078149
Weight
27.3900 lb
Features
  • 0...40 °C (32...104 °F)
  • Suitable for a wide variety of applications
