Hubbell HBL5369EBKCONN, 20A 125V, 5-15R, 12/3 SO

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL5369EBK | Codale Part # 4118325
$133.95/ea
ea
Log in or register to view your price, purchase history, and more!
10 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet Product Catalog Page
Straight Blade Devices, Female Connector, Insulgrip Heavy Duty, Industrial/Commercial Grade, Straight, 2-Pole 3- Wire Grounding, 20A 125V, 5-20R, Black, Single Pack, Rated for 12/3 SO.

Technical Information

Amperage
20 Amp
Applications
Industrial/Commercial
Conductor Size
18-10 AWG
Contact Material
Brass
Current
20 Amp
Flamability Class
UL 94 HB Or Better
Horsepower
1 hp
NEMA
5-20R
Number of Phases
1 Phase
Number of Poles
2-2 Pole
Number of Wires
3 Wire
Operating Temperature
-40 degrees C
Screw Material
#8-32 Brass
Standard
C22.2 No. 42 File 280,CSA,NEMA® WD-6,UL,UL498 File E1706
Style
Standard
Temperature Rating
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Type
Connector Body
Voltage
125 Volt
Wire Count
3
Wire Size
18-10 AWG

Manufacturer Information

Brand
Hubbell Incorporated

General Product Info

12-Digit UPC
783585541396
Color
Black
Product Series
Insulgrip
Product UPC
78358554139
Weight
0.15 lb

Dimensions

Height
1.6 Inch
Length
2.91 Inch
Width
1.900 in

Certifications and Compliance

Country of Origin
USA
Features
  • Individual wiring terminals completely enclosed
  • Powerful, offsetting cord grips clamp on individual conductors
  • Fast lead assembly screws
  • Beveled housing prevents snagging
