HWDK RC108LATR COMBO, 15A SP & 15A1

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # RC108LATR | Codale Part # 4128320
$16.70/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Switches and Lighting Controls, Combination Devices, Residential Grade, 1) Single Pole Toggle, 1) Single Tamper Resistant Receptacle, 15A 120VAC, SelfGrounding, Side Wired

Technical Information

Actuator
Toggle
Amperage
15 Amp
Applications
For Residential Use
Contact Configuration
Two Position
Contact Rating
15A
Current
15 Amp
Mounting Type
Screw
Number of Poles
1 Pole
Operating Cycles
30k
Operating Temperature
Max Continuous- 60 Degrees C, Minimum- -20 Without Impact
Size
Standard Size
Standard
UL
Switch Type
Toggle
Tc Connection
Side Wired
Temperature Rating
-20 to 60 degrees C
Type
Tamper-Resistant, Traditional
Voltage
120 Volt
Wattage
1800 Watt

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Trade-Select™

General Product Info

12-Digit UPC
883778302268
Product UPC
88377830226
Weight
0.1500 lb

Dimensions

Height
1 Inch
Length
4.4 Inch
Width
2.0 in

Certifications and Compliance

Country of Origin
China
Features
  • Quiet snap action mechanism
  • Self-grounding staple is standard
  • Elongated strap with continuous plaster ears
  • Tamper Resistant Receptacle
