Hubbell HBL5469VY 20 Amp 250 Volt 2-Pole 3-Wire NEMA 6-20R Yellow Straight Blade Connector Body

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL5469VY | Codale Part # 4129192
$98.99/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Straight Blade Devices, Female Connector Body, Valise Series, Industrial/Commercial Grade, Straight, 2-Pole 3- Wire Grounding, 20A 250V, 6-20R, Yellow, Single Pack.

Technical Information

Amperage
20 Amp
Applications
Industrial/Commercial
Conductor Size
14-12 AWG
Current
20 Amp
Material
Nylon
NEMA
6-20R
Number of Conductors
3-Wire Grounding
Number of Poles
2-2 Pole
Number of Wires
3 Wire
Operating Temperature
-40 degrees C
Size
Standard
Standard
C22.2 No. 42 File 280C,CSA,NEMA® WD-6,UL,UL498 File E1706
Style
Standard
Tc Connection
Screw Terminals
Temperature Rating
-40 to 75 C
Type
Valise
Voltage
250 Volt
Wattage
5000 Watt
Wire Count
3
Wire Size
18-12 AWG

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Straight Blade

General Product Info

12-Digit UPC
783585013190
Color
Yellow
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Product Series
Valise
Product UPC
78358501319
Weight
0.15 lb

Dimensions

Height
0.88 Inch
Length
2.38 Inch
Width
1.25 in

Certifications and Compliance

Country of Origin
Puerto Rico
Features
  • Hinged one piece body design for easy assembly
  • Powerful, offsetting cord grips clamp on individual conductors
  • Assembly screws are captive and will not fall out while wiring
  • Standard Product
