Burndy YSV28FXB 4/0 FLEX BUTT SPLICE F

Manufacturer: Hubbell-Burndy | Catalog # YSV28FXB | Codale Part # 4141578
$45.20/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Buy American Compliant Buy American Compliant Primary Spec Sheet
Hylink-Splice-Belled Long Barrel, 4/0 Str. (550/24) 4/0 AWG, 3.72 in L, UL Listed 90 Deg C,600 Volts to 35 kV.

Technical Information

Applications
For Higher voltage applications
Color Coding
Purple
Conductor Size
4/0 AWG
Connection Type
Splice
Material
Copper
Plated?
Yes
Plating Type
Tin
Size
3.72 IN Length X 1.77 IN Dimension B
Temperature Rating
90 C
Type
Splice
Voltage
35,000 Volt

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Burndy

General Product Info

12-Digit UPC
781810041468
Color
Black
Product UPC
78181004146
Weight
0.2100 lb

Dimensions

Height
0.77 Inch
Length
3.72 Inch
Overall Length
3.72 in
Width
0.77 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
CSA
No
Features
  • Features: Long Barrel Length: High Voltage Terminations, Four (4) Center Conductor Stops: Provides A Center Wire Stop For Proper Conductor Insertion, High Pull Out Force: Provides Added Security For Greater Mechanical And Electrical Properties, Belled Cable Entry: A Funnel Type Entry Provide Easy Insertion Of Extra Flexible Cables Plus Offers Mechanical Strain Relief For Individual Strands, Color Code: Purple, Tapered End: No, Oil Stop: No, Dieless Tools (number Of Crimps): Y81KFT, Y81KFTMBH, PAT81KFT-18V Tool, (2), Die Index: 15 Element A, Tools, Die Set Catalog Number, And (number Of Crimps): Y35, Y39, Y750 Tool, U28RT Die, (4), Y46 Tool, U28RT Die With PUADP-1 Adapter, (4), Conductor Type: Flexible Copper, Wire Strip Length: 1-7/8 IN
Conductor Type
  • CU C Solid-Size
  • CU C Str-Size
