Hubbell HBL29W75 CONN, w/TIGHT 3P 30A 250V L15-30R, YL

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL29W75 | Codale Part # 4160021
$227.63/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page
Watertight Devices, Twist-Lock® Connector, 30A, 3 Phase 250V AC, 3 Pole, 4 Wire, Thermoplastic elastomer, NEMA L15-30R, Yellow

Technical Information

Amperage
30 Amp
Applications
Industrial/Commercial
Body Material
Thermoplastic Elastomer
Connection Type
Screw
Contact Material
Nickel Plated Brass
Current
30 Amp
Material
Thermoplastic
NEMA
L15-30R
Number of Conductors
4
Number of Phases
3 Phase
Number of Poles
3-3 Pole
Number of Ports
3
Number of Wires
4 Wire
Operating Temperature
-40 degrees C
Screw Material
Nickel Plated Brass
Size
2.77 in x 2.77 in x 5.67 in
Standard
ANSI Standards,Meets NEMA WD-1,WD-6
Tc Connection
Terminal Screws
Temperature Rating
-40 to 60 degrees C Continuous
Type
Industrial Grade
Voltage
250 Volt
Wire Count
4

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock®

General Product Info

12-Digit UPC
783585131887
Color
Yellow
Environmental Conditions
Water Tight
Product UPC
78358513188
Weight
1.0200 lb

Dimensions

Diameter
2.77 Inch
Height
5.67 Inch
Length
5.67 Inch
Width
2.77 in

Certifications and Compliance

Country of Origin
China
Features
  • Smooth body design minimizes collection points simplifying the wash down process
  • Strain relief nut always seals on the body, minimizing debris collection
  • Stainless steel hardware and corrosion-resistant connection points
