Wattstopper DW311W Dual Technology 0-10V Dimming Wall Mounted Occupancy Sensor, 120/277V, White

Manufacturer: Legrand WattStopper | Catalog # DW-311-W | Codale Part # 4166356
$309.56/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Installation / Instruction Manual CAD Drawing #1 CAD Drawing #2 CAD Drawing #3
The DW-311 dual technology dimming wall switch sensor can turn lights OFF and ON based on occupancy and allow the user to increase or decrease the lighting level. It combines the benefits of passive infrared (PIR) and ultrasonic occupancy detection technologies and works with 0-10 VDC dimming drivers and ballasts to control lighting loads including LEDs. (white)

Technical Information

Amperage
8.3 Amp
Applications
For Offices, Conference Rooms, Lunch/Break Rooms, Commercial
Connection Type
Wired
Enclosure
Plastic Housing
Indicator
True
Input Voltage
120/230/240/277 VAC
Mounting Type
In-Wall
Sensing Range
Major motion, PIR 35 x 30, Ultrasonic 20 x 20 Minor motion, PIR 20 x 15, Ultrasonic 15 x 15
Sensor Type
Occupancy
Standard
CSA C22.2 No. 14,IEC 60947-3,UL 508
Type
Automatic, Metered, Service Entrance, Advanced
Voltage
120/277 Volt
Wattage
1200 Watt

Manufacturer Information

Brand
Legrand
Sub Brand
Pass & Seymour

General Product Info

12-Digit UPC
754182939428
Color
White
Finish
Matte
Product UPC
75418293942
Weight
0.4400 lb

Dimensions

Depth
1.81 Inch
Height
2.73 Inch
Length
2.73 Inch
Width
1.75 in

Certifications and Compliance

Country of Origin
China
Features
  • Color-matched lens and low profile for appealing design
  • Supports Partial-ON operation for energy code compliance or incentives
  • 120/277VAC and 347VAC models
  • Allows fully functional multi-way control from up to four switch locations
  • Defaults to Manual-ON operation for maximum energy savings
  • High sensitivity and dense coverage for exceptional performance
