Panduit LAB2/0-12-5 Pan-Lug™ Aluminum 1 Hole Compression Lug

Manufacturer: PANDUIT | Catalog # LAB2/0-12-5 | Codale Part # 4169969
$5,917.83/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Prop 65 Warning Prop 65 Warning Buy American Compliant Buy American Compliant Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
The LAB2/0-12-5 Aluminum Compression Connector Lug, two-hole, is manufactured from high conductivity thick wall aluminum with an enclosed barrel for harsh environments. The color-coded barrels are marked with Panduit and specified competitor die index numbers for proper crimp die selection. Factory pre-filled with joint compound andtin-plated to inhibit corrosion. cULus listed up to 35kV and temperature rated to 90.C.

Technical Information

Angle
Straight
Barrel Length
1.55 in
Base Material
Aluminum
Cable Size
AWG
Color Coding
Olive
Material
Aluminum
Number of Holes
2 Hole
Size
2/0 AWG Code
Stud Size
1/2 In.
Tongue Thickness
0.25 in
Tongue Type
Standard
Tongue Width
0.94 in
Type
Compression Lug
Voltage
35,000 Volt

Packaging

Pkg Qty
5

Manufacturer Information

Brand
Panduit Corp.
Sub Brand
Pan-Lug™

General Product Info

12-Digit UPC
074983911301
Color
Olive
Product UPC
07498391130
UNSPSC
39121405
Weight
0.7000 lb

Dimensions

Overall Length
5.55 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
India

Certifications & Compliance

Prop 65 Warning
No
Standards and Certifications
  • Standards Met: C22.2 No. 65-13, 486A-486B File #E52164
Prop 65
  • No
