Product image for Hoffman PTHW482424GF ProTek D-H Fan Packages, Type 1, 48.54x23.62x24.02, Lt Gray, Steel, Window
Image thumbnail 0
Image thumbnail 1
Email

Hoffman PTHW482424GF ProTek D-H Fan Packages, Type 1, 48.54x23.62x24.02, Lt Gray, Steel, Window

Manufacturer: nVent Hoffman | Catalog # PTHW482424GF | Codale Part # 4174667
$4,708.25/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
ProTek Double-Hinged Fan Package cabinets are an excellent, off-the-shelf choice for mounting 19-inch rack, panel-mounted devices or other electronic equipment. An integral top solar/drip shield and thermostatically-controlled fans provide airflow to cool internal equipment. Cabinets are available in UL Type 3R for outdoor use. A UL Type 1 window version is available for indoor applications. The cabinets are designed to provide both front and rear access to 19-inch rack-mounted equipment. They provide protection against water, dirt and other contaminants. ProTek is an excellent choice for applications where space is at a premium and the only option is wall mounting. ProTek comes in a broad range of sizes, materials and configurations to meet many demanding applications.

Technical Information

Applications
Networking, Storage and Data Center; Controls and Drives
Body Thickness
1.9 mm
Color Coding
RAL 7035
Material
Steel
Rack Unit
26
Standard
CUL Listed Per CSA C22.2 No. 94,File Number E61997,IEC 60529,IP30 Or IP 32,NEMA / EEMAC: Type 1 Or 3R,Solid Door: Type 3R,UL 508A Listed,Window Door: Type 1
Type
Data Networking Wall Mounted Cabinets

Manufacturer Information

Brand
nVent Hoffman
Sub Brand
ProTek

General Product Info

12-Digit UPC
783510236557
Color
Lt Gray
Finish
Gray
Product UPC
78351023655
Weight
180 lb

Dimensions

Depth
24.02 Inch
Height
28-3/4 Inch
Length
57 Inch
Width
23.62 in
Features
  • Front and rear access to 19-inch rack equipment provided by three-part design: door, center section and wall section
  • Solid door provides complete physical and visual protection
  • Integral top solar/drip shield
  • Two thermostatically controlled, long-life, high-performance fans mounted into top
  • Window door, made of .25-inch scratch-resistant safety glass and mechanically fastened, provides visual monitoring of internal equipment while maintaining equipment protection
  • All seams are fully welded and ground smooth
  • Perforated, vented base with internal, expanded metal, serviceable filter
  • Door, center section and wall section are provided with ground studs to facilitate proper bonding and grounding of the cabinet
  • Premium seamless, foam-in-place gasket prevents contaminants from entering the cabinet
  • Key-locking wing knob provides access control to the cabinet; two keys are included with each cabinet
  • One set of plated, self-grounding, tapped 10-32 rack angles per EIA universal spacing standards, adjustable front-to-back within the center section of the cabinet
  • Additional rack angles in tapped- or square-hole versions can be added to the cabinet
  • Wall section welded panel studs which accommodate standard panels (steel and wood available), can be ordered separately
