Hubbell ATP1500CRPAT PIR OCCSENS, CEILING, 1500 SQ FT, w/R

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # ATP1500CRP | Codale Part # 4179196
$276.44/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Switches and Lighting Controls, Occupancy Sensors, Adaptive Technology Passive Infrared Ceiling Sensor, 1500 Square Feet Coverage, With Relay

Technical Information

Applications
Compatible with most LED and CFL
Indicator
PIR= Red LED
Material
ABS Plastic
Mounting Type
Ceiling Mount
Operating Cycles
6k
Operating Temperature
0 To 40 degrees C
Sensing Range
8 to 12 Feet Mounting Height
Standard
ASHRAE 90.1,CULus,UL244A
Style
Ceiling Mount
Type
Non-Reversing
Voltage
24 Volt

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
HMOSS

General Product Info

12-Digit UPC
783585392523
Color
White
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Product Series
Passive Infrared
Product UPC
78358539252
Weight
0.6000 lb

Dimensions

Height
1-1/2 Inch
Length
7 Inch
Width
5.6 in

Certifications and Compliance

Country of Origin
China
Features
  • Coverage 1500 sq. ft. (360°) with photocell and isolated relay, low voltage sensor
  • Long range major motion detection
  • Office White ABS enclosure blends with ceiling tile
  • Relay to interface with auxiliary systems such as HVAC
  • Red LED indicates passive infrared detection
  • Install and Forget\" operation. Auto-adjusting adaptive technology eliminates manual adjustments
  • With Photocell and Relay
