Elite Lighting B26IC-AT-W 6" Shallow Air Shut IC Housing w/ Quick Connector

Manufacturer: Elite Lighting | Catalog # B26IC-AT-W | Codale Part # 4205328
*Call For Price*
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
New construction, thermally protected, IC rated specification grade recessed housing. Accommodates up to 75W PAR30, R30 lamps, 60W A19 lamps and 65W BR30 lamps. Furnished with preinstalled adjustable bar hangers. Junction box is provided with four ." KOs, one ." KO and four Romex knockouts with strain relief.

Technical Information

Aperture Size
6 in

Manufacturer Information

Brand
Elite

General Product Info

12-Digit UPC
847801018793
Product UPC
84780101879
  • Meets all national airflow requirements
  • Preinstalled adjustable bar hanger
  • Thermally Protected Shallow IC housing
  • Adjustable socket bracket
  • Special screw on the frame locks bar hangers in place which prevents the housing from any movement once installed
  • 5-\" height allows use in 2\" x 6\" joist construction
  • Preinstalled socket cap provides electrical contact protection against dust, paint and overspray
  • Dependable, favorable design and effortless installation
  • Designed for 2\" X 6\" Joist Construction
  • Wire through junction box
  • Air-Shut Gasket to prevent air flow form heated or air conditioned spaces
  • For Feed-through wiring
  • For Damp location
  • For Direct contact with insulation
