Product image for Eaton Electrical CHMP100R3C 600 VAC 250 VDC 100 Amp NEMA 3 Line Terminal 3-Pole Molded Case Motor Circuit Protector
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Eaton Electrical CHMP100R3C 600 VAC 250 VDC 100 Amp NEMA 3 Line Terminal 3-Pole Molded Case Motor Circuit Protector

Manufacturer: Eaton Cutler-Hammer | Catalog # HMCP100R3C | Codale Part # 421724
$1,478.47/ea
ea
Log in or register to view your price, purchase history, and more!
1 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Eaton molded case circuit breaker accessory motor protection, Motor circuit protector, 100 A, Three-pole, Frame J-K, 300-1000 A, Series C, Non-aluminum

Technical Information

Actuator
Toggle
Amperage
100 Amp
Applications
For Motor Starters Equipped with Electronic Overload Relays
Conductor Size
14-1/0 AWG
Frame
F
Interrupt Rating
65 kAIC
Mounting Type
Free Standing
Number of Poles
3 Pole
Temperature Rating
-4 to 158 degrees F
Trip Range
300 - 1000 A
Trip Type
Thermal Magnetic
Type
Standard
Voltage
600 VAC, 250 VDC

Manufacturer Information

Brand
Eaton

General Product Info

12-Digit UPC
786679150856
Product UPC
78667915085
Weight
4.5 lb

Dimensions

Height
5 Inch
Length
8 Inch
Width
5 in
