Hubbell CS6377 Locking INLT, 50A 125V, 2P3W

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # CS6377 | Codale Part # 4230598
$404.12/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page
Locking Devices, Twist-Lock®, Industrial, Flanged Inlet, 50A, 125V, 2-Pole 3-Wire Grounding, Non-NEMA, Screw Terminal, Steel

Technical Information

Amperage
50 Amp
Applications
Extra Heavy Duty Industrial
Conductor Size
6 AWG
Current
50 Amp
Dielectric Strength
Withstands 2,000V minimum
Material
Thermoplastic
Mounting Type
Screw
Number of Phases
1 Phase
Number of Poles
2 Pole
Number of Wires
3 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
CSA C22.2 No.42,UL 498
Tc Connection
Pressure Screw Terminals
Type
Single, Locking, Industrial Grade
Voltage
125 Volt
Wattage
6250 Watt
Wire Count
3
Wire Size
10-6 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock®

General Product Info

12-Digit UPC
783585871356
Color
Metallic
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Product UPC
78358587135
Weight
0.80 lb

Dimensions

Height
2.17 Inch
Length
3-1/2 Inch
Width
2.62 in

Certifications and Compliance

Country of Origin
USA
Features
  • Metallic flanged casing provides maximum strength and protection
  • Thermoset interior provides superior heat resistance
  • Standard Product
